AUWELD MAX 120 PLASMA CUTTING MACHINE 3PH/415V

Product Specification:

• Welding Process : MMA (SMAW), CUT
• Input Power Voltage (V) : Three Phase, AC380V±15%
• Input Voltage Frequency (Hz) : 50/60
• Rated Input Power Capacity (kVA) : 15.2 kVA (CUT), 9 kVA (MMA)
• Rated Input Current (A) : 23.0 A (CUT), 13.7 kVA (MMA)
• Output Current Range (A) : 20 – 100 A (CUT), 20 – 240 (MMA)
• Rated Output Voltage (V) : 120 V (CUT), 29.6 V (MMA)
• No Load Voltage (V) : 304 V (CUT), 67.5 V (MMA)
• Duty Cycle (%) : 60
• Efficiency (%) : 85
• Arc Striking Method: Non-Striking
• Post-gas Time (s) : CUT: 0 – 30s, MMA: 0 – 80s (Arc end current)
• Pre-gas Time (s) : CUT: 0.1 – 5.0s, MMA: 0 – 80s (Arc start current)
• Cutting Thickness (mm) : 40
• Suggested Cutting Thickness (mm): 25
• Air Pressure (MPa) : 0.4 – 0.6
• Power Factor (%) : 0.93
• Insulation Class : F
• Protection Class: IP21S
• Product Dimensions : 622mm x 310mm x 480mm
• Product Weight : 51.5 kg
• Industrial Application : Maintenance Repair, Metal Fabrication

Product Features:

• Automatic Overload Protection Function; prevent machine from damage if the duty cycle is exceeded or air flow is blocked
• Deep welding pool, beautiful welding seam
• Integrated wired feeder and powe
• Smooth and spatter-free start
• User-friendly, high welding speed
• Voltage control
• Simple-to-Use Operator Interface
• Industrial Application : Maintenance Repair, Metal Fabrication, Shipyard, Oil & Gas

Include Item(s):

• 1 pc PT80 Plasma Torch (5m)
• 1 pc Welding Cable with Earth Clamp (2m)
• 1 pc Air Filter
• 2 pcs 35mm Cable Connector
• 1 pc Power Cable (2m)

Picture are for illustration purpose only, actual may vary. Price and specifications are subject to change without prior notice.
